Sunday, May 8, 2016

No, not yet

Not really working on the boat full time yet. I've sold my soul to the Gubment till the end of the month. :-)  I have been acquiring materials that'll be needed to get some of the underwater hardware ready.
Some of the stainless for skeg & rudder
Decided over the winter to not use aluminum for the skeg. Stainless, IMHO is the much better choice. This means a few more boat bucks but well worth it. I've found a local machine/fab shop that can cut & assemble my rudder as soon as the farmers are done with their planting season.

Been out in the shed a few times but so far it's been cool & damp. The ground is still soft and one of my first chores will be to level the boat. Not much sense in doing that till things are dried up.
Everything pretty much where I left it.
We picked up a Honda EU2000i generator to use on the boat (and for other stuff). I'm thinking (always thinking) of building in a locker for it on the transom. One of my weaknesses when it comes to equipment like this is for 'add-on' gadgets and low and behold they have 'add-ons' for the EU2000i! Who knew!. Below is a TinyTach & hour meter. IIRC it was about $59 US.
TinyTach installed.
Had a few minor issues getting it in place. I think my genny is a newer production model and has a sensor in the crank case ventilation line. This prevented the bracket from going into place.
Sensor on crank case vent line.
The hose was about 3/4" longer than necessary so I clipped it off and stuck it back in the crank case. Bracket then went back into place nicely.


Still had a bit of an issue with clearance for the side cover. Trimmed some of the plastic off the back and it now fits fine.
Trimmed plastic, trial and error method.
While I was at it I pulled out our old 950 watt generator. This poor little thing had been sitting in the garden shed for about 8 yrs or so, neglected.
IIRC I used this thing once.
Lori bought this for our old boat many years ago. Never really had too much use for it but just kept moving it from one part of the shed to another. With a little help from some Quick Start it started after about 10 pulls and purred away like a kitten with 8 yr old mixed gas in it too!


So, what's next. I will be getting the engine ready to go to the Yanmar dealer for service. Almost all the parts are on hand for the service. I have to build a wagon to haul it around on. That'll likely be next weekend. When the crops are planted the machine/fab shop will start on the rudder. Hopefully by the end of this month it'll be warm 'nuff to get the stringers & engine beds installed so I can sit the engine in place.



 Big goals.

Standby.....

PS. Welcome back!

Wednesday, March 2, 2016

Drive line Dimensions

I've now completed the reassembly of the Python Drive with the longer shaft.
The thrust bearing end
The above pic is of the thrust bearing section of the Python Drive. It is bolted to one of the two CV joints. I did this now just to squeeze the dust caps onto the CV joints after being filled with grease.
Drive adapter plate end
The above pic is of the drive adapter plate end that will get bolted to the output flange of the engine/transmission. Again, I bolted it on just to press the dust covers into place.

Now I can figure out the total drive line configuration. I know the engine length from drive pulley to the output flange on the transmission and the designers specification for the propeller shaft length. Now I know the exact length of the extended Python Drive shaft.
Drive line dimensions
Still some figuring to do when I build the support frame for the Python Drive but that should come relatively easy once I get the propeller shaft tube installed.

Next up, reassembly of the engine control panel for the Yanmar engine. Yeah, I tore it apart. It'll have to go back together for restarting the engine this spring.

Standby....

Tuesday, February 23, 2016

Early season post

Howdy folks.

Rough winter huh? I spent some of it down in ole' Mexico. We got lucky and missed the cold spell & huge dump of white crap that hit our lil' part of the world. :-)  It was back to reality & the freezer this week though. While I was in Mexico I ordered the propeller shaft & some replacement CV joints for the Python Drive.

Here's what happened to the Python Drive.

When I extended the hull I planned to use a Python Drive and extended shaft. The company was really nice to deal with and sent me the extended shaft (1m). The instructions they provided, a set of photos, illustrated how to remove the CV joints and install the longer shaft. What they didn't show was how to deal with the thread locker (Loctite???) they used to secure the splines to the CV joint.
Cracked bearing race
My local mechanic tried to press out the shaft and maxed out his 20 tonne press. I took the unit to the local marine machine shop and after a couple weeks of waiting no word so I stopped in and managed to catch a guy who would give it a shot. He followed the directions and we ended up destroying the CV joint. The force placed on the shaft was transferred by the ball bearings to the bearing race which eventually broke it. It snapped at 24,000 lbs pressure.

So long story short I contacted the company expressing my displeasure in their directions. They offered no consolation at all. They were willing to sell me two new CV's at 200 euros each!

I went to work on the ole' Interwebs using my marine engineering logistics background and identified the CV joints as being the exact same ones used in mid-late 90's Jeep Liberties & Cherokee's. Next came eBay and Google and I located a pair for under $40 USD each! They were waiting the same day I picked up the prop shaft.
New Jeep CV joint
The new CV's were a perfect match. I was a little worried with dimensions on the Python being metric and the Jeep CV's in standard.
Mating CV to shaft
The CV's were fitted with thread locker as per instructions. The dust boots were slipped on beforehand.
Dust boots slid on the shaft
I'll try to get a pic of the whole unit once the thread locker has set and I get the dust boots in place. Grease will be added as well.

That's about it for now. Going to try to dig myself into the boat shed this week. Need to take some measurements for the skeg & rudder shaft. I'm not going to use the welded aluminum skeg thinking the heavy stainless channel being a better choice.

Standby...

Sunday, October 18, 2015

White Stuff from the Sky

Well the first white stuff (in this case hail) has fallen from the sky. The high temp for yesterday was about 4 C. I've pretty much given up on doing any more work on the boat this year. Pulled the epoxy in from the shed about a week ago.

I got done pretty much what I wanted to get done this year. There's some structure in the boat. Getting more done would have been nice. It's only when you do something like this photo below that you realize how big/long a commitment a project like this is:
I lost a good portion of one building season to the fall down the stairs that messed up my knee and back but as you can see we're no less than 5 seasons into this project with at least 2 or 3 to go.

Anyhow, that's it for this year. See you all in the spring.

Stand down.

Sunday, October 4, 2015

Glassing bulkhead panels

I'm alive and well. Lori didn't kill me for using her mixer. That's a $1 yard sale mixer she picked up a few years ago. We've burnt out a couple of them so far mixing glue.

Been down for the count for the better part of 3 days with an ear infection. Right ear deaf as a post & ringing constantly. :-(  Self medicating with Mexican Antibiotics so should be cleared up soon.

Anywho, managed to haul my butt out to the shed this morning. Lil' stiff getting going these cold mornings. I didn't much feel like crawling around in the bottom of the boat so decided to glass the two aft bulkhead panels.
Glass laid out on two bulkheads
This glass is offcuts from other parts of the boat hull. I had planned to use them up for just this purpose. These panels don't have to be totally fiberglassed but I have the stuff and it won't add much extra weight.
Neat coat of epoxy prior to laying the glass
I gooped & peel plied the two panels. First a neat coat of epoxy over the bare wood. When I finished they looked a little dry but they're not. I lifted the ply and the glass underneath is fully wetted out.
Wetted out and peel plied
I'll have to keep my eye on them for awhile. I did roll on extra epoxy and squeegeed them well. I think it's the cheap peel ply doing it. I'll be glad when it's gone but I have a full roll still in the box. Maybe I'll sell it on Kijiji or something.

Tomorrow I'll flip these panels over and do the other side.

Standby....
