Monday, August 27, 2018

Stbd F/W tank bed & chocks

So I'm just getting setup in the boat shed early this morning when I see Jr go shooting off across the back yard and next thing you know it he's on top of the boat shed.
The birds go crazy when he's around and he chases them up there!
So now he's truly stuck. Can't figure out how to get down. I put the extension ladder up on the far side and he takes off to the other side.
Yeah, I'm stuck. So what?
The boy is definitely not the brightest crayon in the box. *sigh* I managed to get him down via the step ladder from the leanto.

Anyhow, I got the starboard F/W tank bed glued & taped.
Starboard side F/W tank bed glued & taped into position.
I'll finish that up tomorrow.

While I was waiting for the fillets to firm up I started on making chocks for the tanks.
First chock gluing up
They're nothing fancy. Just there to keep the tanks from sliding around. I'm going to screw them down so they're easily removable if we have to take a tank out.
Six down, ten to go!
It's just one of those piddly ass'd lil' jobs that has to be done. I'll do the rest when there's time in between other jobs.

I did get to use my VEDB's!
VLDB's
Very
Expensive
Drill
Bits

These  the tapered/countersink/plug cutting kit from Lee Valley Tools. $149

I don't usually buy such good tools but I figured with the amount of joinery I have ahead good tools are probably a good investment. Gonna get one of those pocket jointer thingies too!

That's about it. Time's running out on boat building this season. *Sigh*

Thanks for looking in.

Standby.....



Wednesday, August 22, 2018

M/V She:Kon - Some Odds & Sods

I guess I'd be the 'sod' part of that title. *sigh*

Only 2 weeks left in our boat building season. So much to do. Scrambling around trying to get as much done as I can before I have to shift my attention to the RV and getting it ready for the big trip out west.

Today the Project Manager decided to pay a visit to the Big Blue Boat Shed. He immediately started issuing orders & griping about the lack of progress on the project. I suggested he roll up his fur and pitch in. That didn't go over well. :-(
That's a serious look! I better get to it!
Yesterday and the day before I managed to figure out the tank bed structure and get it tabbed into place. It's a bit of a hodge podge but for someone who's never done this before working on stuff that isn't level & plumb is a bit of a challenge.
Sub framing for the tank bed. This one is for a F/W tank (44 USG)
This morning I glued up the top and filleted & taped it into place. Once that's set up I'll radius the leading edge and apply tape there as well.
Tank bed fitted into place.
There's a fairly hefty gap on the right corner. That's what happens when you have a chunk of cured epoxy filler on the bottom of your level and you don't notice it. *sigh* Had to fit in a few pieces but they'll all be secured adequately enough.

I cut the holes for the retaining straps. These are large enough for 2" straps and are big enough to make fishing them through easy.
Tank bed in place.
Having mixed up too much epoxy I gave the tank bed an extra coat of the stuff. It'll all be sanded & painted before the tank goes on.

While that's curing up I pulled the rudder out from under the boat and decided to give it an extra coat or two (2) of high build epoxy primer. This was the last of my supply.
Rudder getting 2 more coats of primer.
Weather's coming so time to lock up the shed. I still have visions of it flying off in a storm just like Dorothy's house in The Wizard of Oz. *sigh*

Standby....





Friday, August 10, 2018

She-Kon: Back on Planet Earth

Ok, that's enough nonsense. Back on planet Earth in the 21st. century some progress has been made with the boat project.

The stern bearing carrier doesn't sit flush to the keel. The angle of the prop shaft is 8 degrees. I tried a few times to build in a wedge that would correct for this with little success. Yesterday I glued in the bronze nipple that connects the shaft log to the bearing carrier.
Cleaning up the bearing carrier
I used a liberal coating of mold release was to ensure the bearing carrier would separate from the epoxy I used to glue in the bronze nipple. The bearing carrier was used to ensure proper alignment of the shaft etc.
Mold release wax
This is good stuff anytime you've got a part you don't want to stick. I think it's about 98% carnuba wax.
Here you can see the gap between the bearing & the keel
Using a very think mix of epoxy, glass beads, colloidal silica and fiberglass strands I made a mix that I could pump into the space. I used packing tape to keep it from running out. It'll be rough but I can fix that up later. Once it has it's rough shape I might put a layer of carbon fibre over it.
Packing tape used to mold in place the bearing carrier
The rudder has been a royal PITA. A helluva lot more sanding than I ever imagined. I ended up chasing my tail around and around trying to get it fair. Finally I had had enough and had to give up.

Up until today I had no real idea if the rudder would actually fit. I hadn't dry fitted it yet. It was made to the designers specs so I had to place my full faith in him. As it turned out it fits. It's tight getting the bolts in but I can manage. Not really a one person job but a few ups & downs of the step ladder doesn't hurt the waste line! :-)
Success! It fits!
Still some fairing and painting to do on the rudder but I just couldn't help myself fitting it in to see how it looked. Man, it's been a long tough journey to get this far. Little milestones like this is what keeps me going!

Thanks for looking in. Appreciate any/all comments/feedback.

Standby....

Monday, August 6, 2018

She:Kon - Interior Design

Now most people who build their own boats take their ideas for interior design from a number of sources. Magazines, other boats, web sites or boat shows. We decided to deviate from the norm (which is normal for us). Below you'll see what we're planning for the interior of She:Kon.

Engine Room:

Now this looks a lil' far fetched but it's the forced perspective that makes it look bigger than it actually is. The lil' Yammy will fit nicely in this space!
Engine Room.
Helm Station:

From the outset the boat has been designed to accommodate two helm seats.
Helm Position
Deluxe Captains Accommodations

One must certainly be comfortable on those long sea passages.
Captain's Bunk
Captain's Day Cabin
Galley

Especially important to have a nice bright and colourful place for the Cook to prepare delicious 5 course meals for her Captain!
Galley
Dining/Rec room

Personal space can be at a premium on a boat. We've decided to include a nice dining/recreation space.

Dining/Recreation room
Entertainment Center including Ultra Smart TV w/Intergalactic Internets
Main Power Distribution

Often an afterthought is the main power distribution around the ship. This one console will help eliminate all those pesky lil' gremlins that seem to creep into every boat build!
Main Power Distribution Panel
Engine Room Access

Every space on the boat should be accessible by Jefferies Tubes. She:Kon is no different. We've standardized and selected this design for space access.

Jefferies Tube Access
Other/Misc.

There are many other features that will be included in the interior design that will likely be featured in further updates. Here's a few to keep you coming back!

Does Nothing, Goes Nowhere
Computer Navigation System MkI w/Tribbles
Admiral showing off her high tech button pushing method!
And last but not least the dingy.

Admiral chose it herself and it's her personal favorite!

And if you think it is all BS, you'd be wrong and I'm prepared to defend my designs and my vessel!
Prepare a full Photon Torpedo spread! Target their Red Junk sails! Fire!
Standby.....
